5 Statistics/export 03/2013
5.1 Multi-machine views
© Siemens AG 2006-2012 All Rights Reserved
5-234 SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
5.1 Multi-machine views
5.1.1 Multi-machine events
Function description
Event history of several machines in one display:
In the Statistics/Export area under Multi-machine events, any machine can be
entered on an individual basis, or machines can be selected as groups. The
machine events are to be displayed in the form of a chronological list.
The navigation is performed in the machine tree where machines can specifically
be selected, or filters used.
Fig. 5-1: Multi-machine views
Function Description Type
Details of events can be filtered to limit the events
displayed.
An active filter is highlighted in yellow.
DISPLAY
Free text
filter
Definition of partial text over all text columns in the
event list.
After the filter has been applied, only events
containing the partial text are shown.
INPUT
DISPLAY
Trigger
events
After occurrence, the display of events can be
limited with the following triggers:
Trigger events:
MULTIPLE
SELECTION
DISPLAY
