Siemens SIMOCODE pro

Planning/Configuring
6.6 Configuring the DM-F PROFIsafe and integrating it into the fail-safe automation system using PROFIBUS/
PROFIsafe or PROFINET/PROFIsafe
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
53
Integrating SIMOCODE pro V into S7 F/H Systems with DM-F PROFIsafe
Note
Prerequisite
You must
have Version 6.1 or a higher software version in order to integrate
SIMOCODE
pro V into F-Systems with the DM-F PROFIsafe.
Access to the fail-safe output of the DM-F PROFIsafe, which switches the relay enabling
circuits, is via the F-channel driver block F_CH_BO. This block is provided for data type
BOOL outputs of fail-safe DP standard slaves via the GSD. It is also used if
SIMOCODE pro V is integrated with PROFIsafe via the Object Manager
(OM) SIMOCODE pro.
More information: You can find more information in the manual SIMATIC Industrial Software
S7 F/FH Systems - Configuring and Programming.
(https://support.industry.siemens.com/cs/ww/en/view/109742100), Chapter 5.5 "Configuring
fail-safe DP/Standard Slaves//IO-Standard Devices".
Integrating SIMOCODE pro V into S7 Distributed Safety with DM-F PROFIsafe
Note
Prerequisite
You must have Version V5
.4 + SP5 or a higher software version in order to integrate
SIMOCODE
pro V into S7 Distributed Safety with the DM-F PROFIsafe.
More information: See manual SIMATIC S7 Industrial Software Distributed Safety -
Configuring and Programming.
(http://support.automation.siemens.com/WW/view/en/22099875).
Integrating SIMOCODE pro V into STEP 7 Safety (TIA Portal) with DM-F PROFIsafe
Note
Prerequisite
You must have Version
V12 SP1 or a higher software version in order to integrate
SIMOCODE
pro V into STEP7 Safety Advanced or STEP 7 Safety Basic with the DM-
F
PROFIsafe.
More i
nformation: See manual SIMATIC Industrial Software SIMATIC Safety - Configuring
and Programming (https://support.industry.siemens.com/cs/ww/en/view/54110126).
