SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
57
External circuitry
8
8.1
Sensor circuitry for the DM-F LOCAL
Defining the DM-F parameters according to the sensor circuitry
Table 8- 1 Defining the DM-F parameters according to the sensor circuitry, 2-channel with cross-circuit detection
DIP switch
Description
Typical circuit diagram
1
2
3
4
5
6
7
8
1 1 1 — 1 — — — 2-channel, with cross-circuit detection, with
monitored start
DM-F LOCAL, 2-channel, with cross-
circuit detection and monitored start
(Page 64)
1 1 1 — 0 0 — — 2-channel, with cross-circuit detection, with
automatic start
DM-F LOCAL, 2-channel, with cross-
circuit detection and automatic start
(Page 65)
1 0 1 — 1 — — — NC and NO contacts with cross-circuit detection,
with monitored start
DM-F Local, NC and NO contacts, with
cross-circuit detection and monitored start
(Page 66)
1 0 1 — 0 0 — — NC and NO contacts with cross-circuit detection,
with automatic start
DM-F LOCAL, NC and NO contacts, with
cross-circuit detection and automatic start
(Page 67)
0 1 1 — 1 — — — Fail-safe electronic outputs (current sourcing /
current sinking) with monitored start
DM-F LOCAL in conjunction with failsafe
electronic outputs (current sourcing /
current sinking) with monitored start
(Page 68)
0 1 1 — 0 0 — — Fail-safe electronic outputs (current sourcing)
with automatic start
DM-F LOCAL in conjunction with failsafe
electronic outputs (current sourcing) with
automatic start (Page 69)
— = Switch position dependent on further requirements
