External circuitry
8.1 Sensor circuitry for the DM-F LOCAL
58
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
Table 8- 2 Defining the DM-F parameters according to the sensor circuitry, 2-channel without cross-circuit detection
DIP switch
Description
Typical circuit diagram
1
2
3
4
5
6
7
8
0 1 0 — 1 — — — 2 x 1-channel, without cross-circuit detection,
with monitored start
DM-F LOCAL, 2 x 1-channel, without cross-
circuit detection, with monitored start
(Page 70)
0 1 0 — 0 0 — — 2 x 1-channel, without cross-circuit detection,
with automatic start
DM-F LOCAL, 2 x 1-channel, without cross-
circuit detection, with automatic start
(Page 71)
— = Switch position dependent on further requirements
Key:
DIP switch
Meaning 0 = (OFF)
Meaning 1 = (ON)
1
Without cross-circuit detection
With cross-circuit detection
2
NC contact/NO contact evaluation
NC contact/NC contact evaluation
3
2 x 1-channel
1 x 2-channel
4
Debouncing time for sensor inputs 50 ms
Debouncing time for sensor inputs 10 ms
5
Sensor input automatic start
Sensor input monitored start
6
Cascading input automatic start
Cascading input monitored start
7
With start-up testing
Without start-up testing
8
Automatic starting after power failure (not permissible in
conjunction with start-up testing)
No automatic starting after power failure
9
No function
No function
10
No function
No function
