Siemens SIMOCODE pro Manual

Technical data
10.1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
95
Mounting
Snap-mounted onto 35 mm DIN rail or screw-mounted using additional push-in
lugs
Connection
Removable terminal block with screw connection
• Tightening torque
TORQUE 7 lb.in ... 10.3 lb.in
0.8 Nm to 1.2 Nm
• Connection cross-sections
Solid:
2 x 0.5 mm
2
to 2.5 mm
2
/ 1 x 0.5 mm to 4 mm
2
/ 2 x AWG 20 to 14 /
1 x AWG 20 to 12
Finely stranded with end sleeve:
2 x 0.5 mm
2
to 1.5 mm
2
/ 1 x 0.5 mm to 2.5 mm
2
/ 2 x AWG 20 to 16 /
1 x AWG 20 to 14
Engineering
with
• STEP 7 TIA Portal V12 SP1 and higher
• STEP 7 V5.2 and higher (with installed SIMOCODE pro Integration in STEP 7
from SIMOCODE ES 2007 + SP2 and higher)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
