Introduction
SIMODRIVE base line A Start-Up 1-3
1.2. Technical data
Connected load Table 1-1 Connected load
Parameter Min Type Max Unit Remarks
Supply voltage 360 400/ 415 456 V Power
derating in
case of
under 360V
Input frequency 45 50 66 Hz
Output power of infeed
module
5 10 KW
Current consumption
of 1-axis power
module
9 18 A V1
Current consumption
of 2-axes power
module
5/axis 10/axis A V2
Mechanical data Table 1-2 Mechanical data
Parameter
Dimension
( W x H x D, mm)
Weight
(Kg)
Remarks
1-axis
SIMODRIVE base line A
110 x 483 x 271 11 V1
2-axes
SIMODRIVE base line A
110 x 483 x 271 11.5 V2
Environment
operating conditions Table 1-3 Operating environment
Parameter Description Remarks
Temperature
range
0°C ~ +40°C，Max.+55°C；
Power derating in
range of 40°C～+55°C
Annual average:
U=75%；t
d
=17°C
For 30 days (24h) in one year:
U=95%; t
d
=24°C; these days
should be naturally distributed
over the whole year.
Relative
humidity
On all other days (<24h) but
still maintaining the annual
average: U=85%；t
d
=24°C
t
d
: dew point;
U: relative humidity
Height above
sea level
1000m，Max. 2000m；
Power derating in
range 1000m ～2000m
Atmospheric
pressure
Min. 860 mbar (86kPa)；
Max. 1080 mbar (108kPa)
Applicable
standards
DIN IEC 68-2-1
DIN IEC 68-2-2
DIN IEC 68-2-3
DIN VDE0160 5.2.1.3
EN50178
