5.4 Installing the machine
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A
55
5.3.2 Flatness of the supporting surfaces for conventional motors
Shaft height
Flatness
[mm]
≤ 132
0.10
160 0.15
≥ 180
0.20
5.3.3 Machine frame mounting feet (special design)
Please note that when the terminal box is mounted at the NDE (option H08), dimension C
can deviate from EN 50347.
To comply with dimension C according to EN 50347, for machines with double or triple holes
at the NDE, use the appropriate screw bore.
5.4 Installing the machine
5.4.1 Preconditions for smooth, vibration-free operation
Preconditions for smooth, vibration-free operation:
● Stable foundation design
● Precise alignment of the machine
● Correct balancing of parts to be fitted to the shaft end.
● Vibration values in compliance with ISO 10816-3
5.4.2 Aligning the machine to the driven machine and mounting
5.4.2.1 Selecting bolts
● Unless specified otherwise, use fixing screws with at least strength class 8.8 to ISO 898-1
to ensure that the machine is securely mounted and to transmit the torque-generated
forces.
● When selecting the bolts and the design of the foundation, take into account the
maximum forces occurring in the case of a fault such as short circuit or system transfers
in phase opposition, etc.
Request the foundation force values from the Service Center if required.
See also
Tightening torques for screw and bolt connections (Page 141)
