Electrical connection
6.8 Final checks
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A
73
Table 6- 5 Maximum voltage peaks at the motor terminals for line (DOL) motors, converter operation possible
Rated motor voltage
V
Maximum peak voltage at the motor terminals
Û
max
dependent on the rise time t
r
Û
phase-to-phase
V
pk
Û
phase-to-ground
V
pk
Rise time t
r
μs
DC link U
DC
V
≤ 500 V
1500
1100
0.5
750
900
900
0.1
Table 6- 6 Maximum voltage peaks at the motor terminals for motors specifically designed for converter operation (e.g.
VSD 10)
Rated motor voltage
V
Maximum peak voltage at the motor terminals
Û
max
dependent on the rise time t
r
Û
phase-to-phase
V
pk
Û
phase-to-ground
V
pk
Rise time t
r
μs
DC link U
DC
V
≤ 500 V
1600
1400
0.5
750
1000
1000
0.1
> 500 V to 690 V
2200
1800
0.5
1080
1000
1000
0.1
See also
Further documents (Page 140)
6.8 Final checks
Before closing the terminal box/terminal base of the machine enclosure, check the following:
● Establish the electrical connections in the terminal box in accordance with the information
in this documentation.
● Maintain the air clearances between non-insulated parts as described in Chapter
Minimum air clearances. (Page 66)
● Avoid protruding wire ends.
● In order not to damage the cable insulation, freely arrange the connecting cables.
● Connect the machine corresponding to the specified direction of rotation.
● Keep the inside of the terminal box clean and free from trimmed-off ends of wire.
● Ensure that all seals and sealing surfaces are undamaged and clean.
● Correctly and professionally close unused openings in the terminal boxes. Observe the
information in this documentation.
● Observe the information on torques in this documentation.
See also
Tightening torques for screw and bolt connections (Page 141)
