10.9 Machine parts
Standard motors SH 63 ... 355
120 Operating Instructions, 12/2018, A5E38483075A
10.9 Machine parts
Part
Description
Part
Description
1.00
DE bearings
Terminal box, complete
1.30 Bolt 5.43 Entry plate
1.31
Spring lock washer
5.44
Terminal box top side
1.32 Bolt 5.45 Enclosure
1.33
Nut
5.46
Bolt
1.40
End shield
5.47
Bolt
1.43
Shaft sealing ring
5.48
Spring lock washer
1.44
Bearing cover DE, inner
5.49
Self-tapping screw
1.45
Bolt (bearing cover)
5.51
Nut
1.46
Cover ring
5.52
Cable gland
1.47
O ring
5.53
Screw plug
1.48
Self-tapping screw
5.54
O ring
1.49
Bolt
5.55
Nut
1.50
Flanged nut
5.60
Terminal board screw
1.56
Spacer washer
5.61
Bolt
1.58
Spring washer
5.62
Spring lock washer
1.60
Roller bearing
5.63
Mounting rail
1.61
Spring band for end shield hub
5.64
Spring lock washer
1.63
Condensation drain plug
5.65
Bolt
1.65
Grease nipple
5.68
Screw plug
1.67 Bearing cover NDE, outer 5.69 O ring
1.68
Grease slinger (optional)
5.70
Terminal clamp
1.69
Compression spring
5.72
Contact bracket
3.00
Rotor, complete
5.76
Terminal plate / contact bracket
3.02
Locking ring
5.78
Washer
3.03
Locking ring
5.79
Bolt
3.38 Featherkey 5.81 Self-tapping screw
3.88
Featherkey for fan
5.82
O ring
4.00
Stator, complete
5.83
Seal
4.04
Eyebolt
5.84
Terminal box cover
4.07
Housing foot
5.85
Terminal box cover including seal (optional bolt)
4.08
Housing foot, left
5.88
Spring lock washer
4.09
Housing foot, right
5.89
Bolt
4.10 Spring lock washer 5.90 The top side of the terminal box can be rotated 4 x 90
degrees, complete
(for subsequent mounting)
4.11
Bolt
5.91
Bolt
4.12
Nut
5.92
Terminal box cover
4.18
Rating plate
5.93
Seal
4.19
Self tapping screw or slotted pin
5.94
Bolt
