Siemens SIMOTICS GP series - Page 123

Spare parts
10.9 Machine parts
Standard motors SH 63 ... 355
Operating Instructions, 12/2018, A5E38483075A
121
Part
Description
Part
Description
4.20
Cover
5.95
Terminal box top side
4.30 Contact bracket 5.96 Screw plugs
4.31
Grounding bracket
5.97
Nut
4.35 Disk 5.98 Sheet metal nut
4.37
Terminal board
5.99
Adapter plate
4.38
Spring lock washer
6.00
Bearings, NDE
4.39
Grounding screw (self-tapping screw)
6.02
Locking ring
4.40
Disk
6.03
Bearing cover NDE, inner
5.00
Terminal box, complete
6.10
Rolling bearing
5.02
spacer
6.11
Spring band for end shield hub
5.03
Seal
6.12
Locking ring
5.04
Seal
6.20
End shield
5.06
Mounting rail
6.23
Shaft sealing ring
5.08
Spacer sleeve
6.25
Lubrication sleeve
5.09
Bolt
6.27
Bearing cover NDE, outer
5.10
Complete terminal board
6.29
Bolt
5.11
Terminal block
6.30
Bearing cover NDE, inner
5.13
Link rail
6.31
Flanged nut
5.15
Plug
6.65
Grease nipple
5.16
Spring lock washer
6.66
Screw
5.18 Spring lock washer 6.67 Rubber bush
5.19
Bolt
6.72
Grease slinger
5.21
Screw (drilled)
7.00
Ventilation system, complete
5.24
Bolt
7.04
Fan
5.27
Clamp
7.12
Locking ring
5.28
Upper saddle terminal
7.40
Fan cover
5.29 Lower saddle terminal 7.41 bracket
5.36
Spring lock washer
7.48
Washer
5.37
Spring lock washer
7.49
Bolt
5.42
Terminal box housing, including seal
Tools for mounting and withdrawing roller bearings; fans and output transmission elements cannot be supplied.
