Figure 7-1 Lifting and transporting with lifting slings (example diagram)
Procedure for lifting and transporting using eyebolts
For the 1F☐2☐10 motors, you can use eyebolts and a crossbar for lifting and transporting.
WARNING
Incorrect or unused lifting points
Due to incorrect or unused lifting points, the motor can fall and cause death, severe injury and/
or damage to property.
Only lift and transport larger motors using the eyebolts screwed on to the end shields.
Completely screw in the eyebolts and tighten by hand (approx. 8 Nm).
Do not use bent or damaged eyebolts.
Only use eyebolts with laminated 󹪝ber washers.
Loads applied transversely to the plane of the eyebolts are not permitted.
Preparation for use
7.1 Transporting
1FK2 Synchronous Motors for SINAMICS S120
130 Con󹪝guration Manual, 02/2022, A5E46927724B AD
