Motor Power cable
Order number Static torque
M
0
/ Nm
Article number Connector size Cable cross section
1FK2205-4AF 6 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2206-2AF 6.5 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2206-4AF 12 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2208-3AC 16 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2208-4AC 22 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2208-5AC 27 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2210-3AB 30 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2210-3AC 30 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2210-4AB 40 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2210-4AC 40 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2210-5AC 50 6FX☐002-5☐N46-☐☐☐☐ M40 4 x 4.0
High Inertia
1FK2306-2AC 6 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2306-4AC 12 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2308-3AB 18 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2308-4AB 22 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
6FX☐002-5☐N☐☐-☐☐☐☐ = SPEED CONNECT connector; 6FX☐002-5☐A☐☐-☐☐☐☐ = full thread connector
MOTION-CONNECT power cable between the motor and the SINAMICS S120 Booksize Compact
converter
Motor Power cable
Order number Static torque
M
0
/ Nm
Article number Connector size Cable cross section
High Dynamic
1FK2103-2AH 0.64 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2103-4AH 1.27 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2104-4AF 1.27 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2104-4AK 1.27 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2104-5AF 2.4 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2104-5AK 2.4 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2104-6AF 3.2 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2105-4AF 5 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2105-6AF 8 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2106-3AF 9 6FX☐002-5☐G10-☐☐☐☐ M23 4 x 1.5
1FK2106-4AF 12 6FX☐002-5☐G10-☐☐☐☐ M23 4 x 1.5
1FK2106-6AF 16 6FX☐002-5☐G10-☐☐☐☐ M23 4 x 1.5
Compact
1FK2203-2AK 0.64 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2203-4AK 1.27 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2204-5AF 2.4 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2204-5AK 2.4 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
1FK2204-6AF 3.2 6FX☐002-5DN30-☐☐☐☐ M17 4 x 0.75
Technical data and characteristics
6.2 Motor overview / Assignment Motor modules / Power cables
1FK2 Synchronous Motors for SINAMICS S120
92 Con󹪝guration Manual, 02/2022, A5E46927724B AD
