Example of an article number (order number) for a MOTION-CONNECT power cable
Description Position in the article number
1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16
MOTION-CONNECT power cable (exam‐
ple)
6 F X
MOTION-CONNECT 500 5
MOTION-CONNECT 800 PLUS 8
0 0 2 - 5
Without brake cables C
With brake cables D
N 0 6 -
Length code ☐ ☐ ☐ ☐
Power cable between motor and SINAMICS S120 Booksize, DC link voltage 510 V to 720 V DC, (line
voltage, 3 AC 380 V to 480 V)
The following table outlines the available options for the MOTION-CONNECT power cable
between the motor and converter.
MOTION-CONNECT power cable between the motor and the SINAMICS S120 Booksize C/D type
converter
Motor Power cable
Order number Static torque
M
0
/ Nm
Article number Connector size Cable cross section
High Dynamic
1FK2103-2AH 0.64 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2103-4AH 1.27 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2104-4AF 1.27 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2104-4AK 1.27 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2104-5AF 2.4 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2104-5AK 2.4 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2104-6AF 3.2 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2105-4AF 5 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2105-6AF 8 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2106-3AF 9 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2106-4AF 12 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
1FK2106-6AF 16 6FX☐002-5☐N06-☐☐☐☐ M23 4 x 1.5
Compact
1FK2203-2AK 0.64 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2203-4AK 1.27 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2204-5AF 2.4 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2204-5AK 2.4 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2204-6AF 3.2 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
1FK2205-2AF 3.5 6FX☐002-5☐N27-☐☐☐☐ M17 4 x 0.75
Technical data and characteristics
6.2 Motor overview / Assignment Motor modules / Power cables
1FK2 Synchronous Motors for SINAMICS S120
Con󹪝guration Manual, 02/2022, A5E46927724B AD 91
