Siemens SIMOTICS S-1FK2 Configuration Manual

Motor Power cable
Order number Static torque
M
0
/ Nm
Article number Connector size Cable cross section
1FK2204-5AF 2.4 6FX5002-5DF07-☐☐☐☐ M17 4 x 1.5
1FK2204-5AK 2.4 6FX5002-5DF07-☐☐☐☐ M17 4 x 1.5
1FK2204-6AF 3.2 6FX5002-5DF07-☐☐☐☐ M17 4 x 1.5
1FK2205-2AF 3.5 6FX5002-5DF07-☐☐☐☐ M17 4 x 1.5
1FK2205-4AF 6 6FX5002-5DF07-☐☐☐☐ M17 4 x 1.5
1FK2206-2AF 6.5 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2206-4AF 12 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2208-3AC 16 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2208-4AC 22 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2208-5AC 27 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2210-3AB 30 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2210-3AC 30 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2210-4AB 40 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2210-4AC 40 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
High Inertia
1FK2306-2AC 6 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2306-4AC 12 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2308-3AB 18 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
1FK2308-4AB 22 6FX☐002-5☐F10-☐☐☐☐ M23 4 x 1.5
More information on the length code is available in Catalog NC 82 (https://
support.industry.siemens.com/cs/ww/en/view/109746977).
See also
Catalog D21.4 (https://support.industry.siemens.com/cs/de/de/view/109751875)
Technical data and characteristics
6.2 Motor overview / Assignment Motor modules / Power cables
1FK2 Synchronous Motors for SINAMICS S120
94 Con󹪝guration Manual, 02/2022, A5E46927724B AD
