Connecting
5.1 Wiring
SIMOTION C
110 Operating Instructions, 02/2012
Procedure:
1. Insert the Sub-D connector (9-pin) into the drive unit.
2. Open the front door of the SIMOTION C and insert the Sub-D connector (9-pin) into the
X8/X9 socket.
3. Lock the connector using the finger screws. Close the front cover.
Connecting cable
Details about the bus cable, bus connector and installation can be found in chapter
Networking (Page 122).
Note
The maximum cable length is 100 m.
The terminating resistor must be switched in (switch position "On") at the beginning and end
of the bus segment. See figure "Bus connector (6ES7 ...): Terminating resistor connected
and disconnected" in chapter Network components for a PROFIBUS subnet (Page 125)
