Siemens SIMOTION C230-2 User Manual

Technical data
10.1 Technical data
SIMOTION C
174 Operating Instructions, 02/2012
Stepper drive (C230-2, C240)
Table 10- 9 Stepper drive
5 V output signals according to RS422 standard
Differential output voltage V
OD
Min. 2 V (R
L
= 100 Ω)
Output voltage "1" V
OH
3.7 V (I
O
= -20 mA)
4.5 V (I
O
= -100 μA)
Output voltage "0" V
OL
Max. 1 V (I
O
= 20 mA)
Load impedance R
L
: min. 55 Ω
Output current I
O
max. ±60 mA
Pulse frequency f
P
Max. 750 kHz
Cable length: Max. 50 m
● For mixed operation with analog axes, cable length: 35 m
● For asymmetrical transmission, cable length: 10 m
