Siemens SIMOTION C230-2 User Manual

Technical data
10.1 Technical data
SIMOTION C
Operating Instructions, 02/2012
175
Actual value latch time
The following table shows the different latch times Ti of the actual encoder values depending
on the position control cycle clock.
Table 10- 10 Actual value latch time
Actual value latch time Ti [µs]
Position control cycle clock [µs]
C230-2 C240
1500 0 0
1750 0 0
2000 0 0
2250 0 0
2500 0 0
2750 0 2
3000 0 0
3250 0 64
3500 0 0
3750 0 127
4000 0 0
4250 0 189
4500 0 0
4750 0 252
5000 0 0
5250 0 314
5500 0 2
5750 0 377
6000 0 0
6250 0 439
6500 0 64
6750 0 502
7000 0 0
7250 0 564
7500 0 127
7750 0 627
8000 0 0
