Technical data
4.1 Technical data D4x5
SIMOTION D4x5
Manual, 02/2012
63
Digital I/Os (parameterizable)
Table 4- 11 Digital I/Os of the SIMOTION D4x5
Data SIMOTION D425 SIMOTION D435 SIMOTION D445/D445-1
Digital inputs/outputs 8
Max. 6 as high-speed inputs of measuring inputs, max. 8 as high-speed
outputs of output cams/DO
If used as an input:
• Input voltage, rated
value
24 VDC 24 VDC 24 VDC
• Input voltage, for signal
"1"
15 ... 30 V 15 ... 30 V 15 ... 30 V
• Input voltage, for signal
"0"
2)
-3 ... +5 V -3 ... +5 V -3 ... +5 V
Galvanic isolation No No No
Current consumption typ. at
signal level "1"
10 mA at 24 V 10 mA at 24 V 10 mA at 24 V
Input delay, typ. (hardware) L -> H: 5 µs
H -> L: 50 µs
L -> H: 5 µs
H -> L: 50 µs
L -> H: 5 µs
H -> L: 50 µs
Input of measuring input,
reproducibility
5 µs 5 µs 5 µs
If used as an output
• Rated load voltage,
permissible range
24 VDC,
20.4 to 28.8 V
24 VDC,
20.4 to 28.8 V
24 VDC,
20.4 to 28.8 V
• Galvanic isolation
No No No
• Current load, max.
500 mA per output 500 mA per output 500 mA per output
• Residual current, max.
2 mA 2 mA 2 mA
• Output delay, typ./max.
(hardware)
1)
L -> H: 150 µs / 400 µs
H -> L: 75 µs / 100 µs
L -> H: 150 µs / 400 µs
H -> L: 75 µs / 100 µs
L -> H: 150 µs / 400 µs
H -> L: 75 µs / 100 µs
• Output of cam output,
reproducibility
125 µs 125 µs 125 µs
Switching frequency of the outputs, max.
• With resistive load
100 Hz 100 Hz 100 Hz
• With inductive load
2 Hz 2 Hz 2 Hz
• With lamp load
11 Hz 11 Hz 11 Hz
Short-circuit protection Yes Yes Yes
1)
Data for: Vcc = 24 V, load 48 Ohm, H = 90% V
Out
; L = 10% V
Out
2)
The digital inputs are protected against polarity reversal up to -30 V
