Technical data
4.1 Technical data D4x5
SIMOTION D4x5
62 Manual, 02/2012
General technical data
Table 4- 9 Technical data (general)
Data SIMOTION
D425
SIMOTION
D435
SIMOTION
D445
SIMOTION
D445-1
Fan Optional
fan/battery
module
Optional
fan/battery
module
Fan/battery
module included
in scope of
delivery
Double fan/battery
module included
in scope of
delivery
Power supply
• Rated value
• Permissible range
• 24 VDC
• 20.4 to 28.8 V
• 24 VDC
• 20.4 to 28.8 V
• 24 VDC
• 20.4 to 28.8 V
• 24 VDC
• 20.4 to 28.8 V
Current consumption,
typically
1)
600 mA 600 mA 2 A 1 A
Starting current, typ. 6 A 6 A 6 A 5 A
Power loss 15 W 15 W 48 W 24 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE-CLiQ and PROFIBUS interfaces
Digital inputs
Table 4- 10 Digital inputs on SIMOTION D4x5
Data SIMOTION D425 SIMOTION D435 SIMOTION D445/D445-1
Digital inputs 8 8 8
Input voltage
• Rated value
24 VDC 24 VDC 24 VDC
• For signal "1"
15 ... 30 V 15 ... 30 V 15 ... 30 V
• For
signal "0"
2)
-3 ... +5 V -3 ... +5 V -3 ... +5 V
Galvanic isolation Yes, in groups of 4
1)
Yes, in groups of 4
1)
Yes, in groups of 4
1)
Current
consumption typ. at
signal level "1"
10 mA at 24 V 10 mA at 24 V 10 mA at 24 V
Input delay, typ.
(hardware)
L -> H: 50 µs
H -> L: 150 µs
L -> H: 50 µs
H -> L: 150 µs
L -> H: 50 µs
H -> L: 150 µs
1)
Reference potential is terminal G1 or G2
2)
The digital inputs are protected against polarity reversal up to -30 V
