4.1 Technical data D4x5
SIMOTION D4x5
Manual, 02/2012
61
Communication
Table 4- 7 Interface communication
Data SIMOTION D425 SIMOTION D435 SIMOTION D445/D445-1
DRIVE-CLiQ
interfaces
4 4 6
Ethernet
interfaces
2 2 2
PROFIBUS
interfaces
2 2 2
PROFINET
interfaces
Optionally via CBE30:
• 1 interface with 4
ports
• Supports
PROFINET IO with
IRT and RT
• Can be configured
as PROFINET IO
controller and/or
device
Optionally via CBE30:
• 1 interface with 4
ports
• Supports PROFINET
IO with IRT and RT
• Can be configured as
PROFINET IO
controller and/or
device
Optionally via CBE30:
• 1 interface with 4 ports
• Supports PROFINET IO
with IRT and RT
• Can be configured as
PROFINET IO controller
and/or device
Address space
Table 4- 8 Address space
Address space SIMOTION D425 SIMOTION D435 SIMOTION
D445/D445-1
Logical I/O address space in KB 16 KB 16 KB 16 KB
Physical I/O address space in KB
• PROFIBUS (per interface): max.
each for inputs and outputs
• PROFINET: max. each for inputs and
outputs
• 1 KB
1)
• 4 KB
1)
• 1 KB
1)
• 4 KB
1)
• 1 KB
1)
• 4 KB
1)
Permanent process image for
BackgroundTask (I/O variables)
64 bytes 64 bytes 64 bytes
Additional configurable process image for
each cyclic task (I/O variables)
Yes Yes Yes
Address space for each PROFIBUS DP
station
244 bytes 244 bytes 244 bytes
Address space per
SINAMICS Integrated/CX32
(PROFIBUS Integrated)
512 bytes 512 bytes 512 bytes
Address space for each PROFINET
device
1400 bytes 1400 bytes 1400 bytes
1)
When PROFIBUS and PROFINET are used, the total address space applies
