Supplementary system components
6.3 TB30 terminal board
SIMOTION D4x5-2
104 Manual, 02/2012
6.3.3.5 Analog inputs and outputs
Table 6- 8 Terminal block X482
Terminal Designation
1)
1 AI 0+
2 AI 0-
3 AI 1+
4 AI 1-
5 AO 0+
6 AO 0-
7 AO 1+
8 AO 1-
Table 6- 9 X482 wiring
Characteristics Type
Connectable conductor types
- Rigid
- Flexible
- Flexible with end sleeve, without plastic sleeve
- AWG/kcmil
Conductor cross-section
0.14 mm
2
to 0.5 mm
2
0.14 mm
2
to 0.5 mm
2
0.25 mm
2
to 0.5 mm
2
26 to 20
Stripped length 8 to 9 mm
Tool Screwdriver 0.4 x 2.0 mm
Max. cable length 30 m
Note
An open input is interpreted as approximately "0 V".
The power supply of the analog I/Os of the TB30 is via the option slot of the D4x5-2 control
unit and not via X424.
The shield is connected to the control unit. For further information concerning "Establishing a
shield connection", refer to the
SIMOTION D4x5-2
Commissioning and Hardware Installation
Manual, "Connecting I/Os" section.
CAUTION
The common-mode range must not be infringed.
The analog differential voltage signals can have a maximum offset voltage of ±30 V with
respect to the ground potential. If the range is infringed, incorrect results may occur during
analog/digital conversion.
