Component Function

SIMATIC ET 200M Modular I/O system for cabinet installation and high channel densities in the SI‐

MATIC S7-300 packaging system.

SIMATIC ET 200SP Finely scalable I/O system for cabinet installation; ET 200SP features a single-cable

and multi-cable connection with push‑in terminals, compact dimensions, high per‐

formance, and low part variety. With the time-based I/O, signals can be recorded or

output to the precise µs.

SIMATIC ET 200S Finely scalable I/O system for cabinet con󹪝guration and particularly time-critical

applications; including motor starters, safety technology and individual grouping of

load groups.

SIMATIC ET 200AL Modular, distributed I/O system with compact I/O modules in IP65/67; simple in‐

stallation in all mounting positions even in small spaces; front and transverse screw

fastenings on 󹪞at surfaces or on aluminum supporting channels; 󹪞exible connec‐

tion to PROFINET or PROFIBUS or simple integration in SIMATIC ET 200SP.

SIMATIC ET 200pro Modular I/O system with IP65/67 degree of protection for machine-related applica‐

tions with no cabinet; with features such as compact designs, integrated PROFIsafe

safety technology, PROFINET IO connection and live module replacement.

SIMATIC ET 200eco PN Compact block I/O with IP65/66/67 degree of protection for cabinet-free usage in

machines with M12 connection method. Very rugged and resistant encapsulated

metal enclosure.

Other PROFINET IO I/O devices

Drive units with PROFINET IO interface ... convert speed setpoints into signals for controlling the motor and supply the

power required to operate the motors.

Gateways

• IE/AS-Interface link PN IO for the PROFINET IO gateway to AS-Interface

• PN/PN coupler for connecting two PROFINET IO networks

Ethernet

The Control Unit can communicate with the following components via the Ethernet interfaces

or be embedded in an automation environment:

Table 2-4 Components on the Ethernet

Component Function

Programming device (PG/PC) … con󹪝gures, assigns parameters, programs, and tests using the SIMOTION SCOUT Engi‐

neering System (ES).

Master computer … communicates with other devices via UDP, TCP/IP.

SIMATIC HMI device ... is used for operating and monitoring functions. This is not an essential requirement for the

operation of the SIMOTION D410‑2.

Description

2.2 System components

SIMOTION D410-2

26 Equipment Manual, 07/2021, A5E33446720B
