09.02 Start-Up
Siemens AG 6SE7087-6AK85-1AA0
4-51
Rectifier/Regenerating Unit Operating Instructions
8
7
564321
20 ms
#
U
+10 V
-10 V
...
3
2
1
0
P657
CU-AA offset
DAC
Hardware filtering
to terminal block
P655
CU-AA actual values
P656
CU-AA gain
...
...
...
Contents of parameter 001
0
Analog output CUR
U
OFF
=
Parameter value [%]
100%
x (Gain [V] + Offset [V])
Figure 4.4.3 Analog output CUR
