09.02 Connection
Siemens AG 6SE7087-6AK85-1AA0
3-7
Rectifier/Regenerating Unit Operating instructions
Unit Mains supply fuses
Order No. Column 1 Column 2
Siemens (SITOR)
Bussmann
US standard
6SE70 A Type A Type
22-1EC85-1AA0 32 3NE4101 40 170M3608
24-1EC85-1AA0 63 3NE4118 63 170M3610
28-6EC85-1AA0 125 3NE4122 125 170M3613
31-7EE85-1AA0 250 3NE3227 250 170M3616
32-2EE85-1AA0 315 3NE3230-0B 315 170M3617
33-1EE85-1AA0 450 3NE3233 450 170M3620
33-8EE85-1AA0 450 3NE3333 550 170M3622
34-6EE85-1AA0 560 3NE3335 700 170M4617
36-1EE85-1AA0 800 3NE3338-8 900 170M5615
22-7FC85-1AA0 40 3NE4102 50 170M3688
24-1FC85-1AA0 63 3NE4118 63 170M3689
27-2FC85-1AA0 100 3NE4121 125 170M3692
28-8FC85-1AA0 125 3NE3222 160 170M3693
31-5FE85-1AA0 160 3NE3224 —
32-4FE85-1AA0 315 3NE3230-0B —
32-7FE85-1AA0 350 3NE3231 400 170M4693
33-5FE85-1AA0 450 3NE3333 550 170M6693
34-2FE85-1AA0 500 3NE3334-0B —
35-4FE85-1AA0 630 3NE3336 800 170M6696
31-4HE85-1AA0 160 3NE3224 —
32-2HE85-1AA0 315 3NE3230-0B 350 170M6689
32-7HE85-1AA0 350 3NE3231 —
34-2HE85-1AA0 560 3NE3335 —
35-3HE85-1AA0 630 3NE3336 800 170M6696
Table 3.3 Recommended mains fuses
Table 3.3: Semiconductor protection only, lines are not reliably protected
CAUTION
Devices of sizes C and E require semiconductor protection fuses in the network incoming line to protect the
semiconductors according to Table 3.3. For devices with integrated arm-circuit fuses (sizes H and K – see
Table 3.5), no semiconductor protection is required outside the device.
Line protection must be ensured for all device types by assigning a suitable line protection element (e.g. fuse,
line protection circuit-breaker) to the line cross-sectional area as defined in the currently valid standards – e.g.
DIN VDE 0100 Part 430.
