Connection 09.02
3-8 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating instructions
Unit Order No. Built-in F10 DC link fuse
Siemens SITOR Bussmann
US standard
6SE70 A Type A Type
22-1EC85-1AA0 32 3NE4101 35 170L3832 1)
24-1EC85-1AA0 63 3NE4118 80 170L3836 1)
28-6EC85-1AA0 125 3NE4122 —
31-7EE85-1AA0 250 3NE3227 315 170M3696
32-2EE85-1AA0 250 3NE3227 350 170M3697
33-1EE85-1AA0 450 3NE3233 500 170M4695
33-8EE85-1AA0 500 3NE3334-0B 630 170M4697
34-6EE85-1AA0 560 3NE3335 800 170M5698
36-1EE85-1AA0 800 3NE3338-8 1000 170M5700
22-7FC85-1AA0 40 3NE4102 50 170L3834 1)
24-1FC85-1AA0 63 3NE4118 80 170L3836 1)
27-2FC85-1AA0 100 3NE4121 125 170L3838 1)
28-8FC85-1AA0 160 3NE4124 —
31-5FE85-1AA0 200 3NE3225 250 170M3695
32-4FE85-1AA0 315 3NE3230-0B 400 170M4693
32-7FE85-1AA0 350 3NE3231 450 170M4694
33-5FE85-1AA0 450 3NE3333 550 170M4696
34-2FE85-1AA0 500 3NE3334-0B 700 170M5697
35-4FE85-1AA0 710 3NE3337-8 900 170M5699
31-4HE85-1AA0 200 3NE3225 250 170M3695
32-2HE85-1AA0 315 3NE3230-0B 400 170M4693
32-7HE85-1AA0 350 3NE3231 450 170M4694
34-2HE85-1AA0 560 3NE3335 700 170M5697
35-3HE85-1AA0 710 3NE3337-8 900 170M5699
Table 3.4 Built-in DC link fuse
1) Not a US standard
