5.3 Screwing the transport units together
NOTICE
Material damage caused by mechanical pressure on components
Stress that occurs during transport may exert mechanical pressure on the components.
Material damage can result.
● Line the cabinets up precisely with each other in order to avoid shearing forces when the
base units are screwed together.
● Install the converter only on a level and horizontal surface.
Preparation
Ensure that access to the holes in the bottom of the cabinets is unobstructed. Remove the
guard covers.
To screw the transport units together, you will need the following mounting hardware:
● Hexagon nuts ISO 4032-M8-8 A2L
● Contact washers SN70093-8-FSt-mechZn-f
● Threaded pin M8 x 15.5
● Self-adhesive sealing strips
Screwing the transport units together
To screw transport units together, proceed as follows:
1. Affix the self-adhesive sealing strips ①.
2. Align the transport units.
