Gearbox
9.3 Motors with helical and bevel gearboxes
Synchronous Motors 1FK7
Configuration Manual, (PFK7S), Edition 12.2006, 6SN1197-0AD16-0BP1
235
Order no. geared motor + order codes and or
Q @@ G2 @
1)
G2 @
1)
4th order code,
torque bracket for bevel (K) and worm gear units (S)
Torque bracket position Gear unit type and size
Torque bracket Side 1, eye side 4 K 102, S 102 Q 1 2 G 2 3 G 2 8
Side 1, eye side 3 K 102, S 102 Q 1 3 G 2 7 G 2 4
Side 5, eye side 4 K 102, S 102 Q 1 4 G 2 3 G 2 8
Side 5, eye side 3 K 102, S 102 Q 1 5 G 2 7 G 2 4
Side 2, eye side 4 K 102 Q 1 6 G 2 3 G 2 8
Side 2, eye side 3 K 102 Q 1 7 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 202, S 202 Q 2 2 G 2 3 G 2 8
Side 1, eye side 3 K 202, S 202 Q 2 3 G 2 7 G 2 4
Side 5, eye side 4 K 202, S 202 Q 2 4 G 2 3 G 2 8
Side 5, eye side 3 K 202, S 202 Q 2 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 302, S 302 Q 3 2 G 2 3 G 2 8
Side 1, eye side 3 K 302, S 302 Q 3 3 G 2 7 G 2 4
Side 5, eye side 4 K 302, S 302 Q 3 4 G 2 3 G 2 8
Side 5, eye side 3 K 302, S 302 Q 3 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 402, S 402 Q 4 2 G 2 3 G 2 8
Side 1, eye side 3 K 402, S 402 Q 4 3 G 2 7 G 2 4
Side 5, eye side 4 K 402, S 402 Q 4 4 G 2 3 G 2 8
Side 5, eye side 3 K 402, S 402 Q 4 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 513 Q 5 2 G 2 3 G 2 8
Side 1, eye side 3 K 513 Q 5 3 G 2 7 G 2 4
Side 5, eye side 4 K 513 Q 5 4 G 2 3 G 2 8
Side 5, eye side 3 K 513 Q 5 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 613 Q 6 2 G 2 3 G 2 8
Side 1, eye side 3 K 613 Q 6 3 G 2 7 G 2 4
Side 5, eye side 4 K 613 Q 6 4 G 2 3 G 2 8
Side 5, eye side 3 K 613 Q 6 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 713 Q 7 2 G 2 3 G 2 8
Side 1, eye side 3 K 713 Q 7 3 G 2 7 G 2 4
Side 5, eye side 4 K 713 Q 7 4 G 2 3 G 2 8
Side 5, eye side 3 K 713 Q 7 5 G 2 7 G 2 4
Torque bracket Side 1, eye side 4 K 813 Q 8 2 G 2 3 G 2 8
Side 1, eye side 3 K 813 Q 8 3 G 2 7 G 2 4
Side 5, eye side 4 K 813 Q 8 4 G 2 3 G 2 8
Side 5, eye side 3 K 813 Q 8 5 G 2 7 G 2 4
1)
Options Q12 to Q85 can be combined only with the following order codes:
B.. or E.. with G23 or G24 or G27 or G28
