Siemens SINAMICS V20 User Manual

SINAMICS
SINAMICS V20 Converter
Operating Instructions
10/2019
A5E34559884
-012
Preface
Fundamental safety
instructions
1
Introduction
2
Mechanical installation
3
Electrical installation
4
Commissioning via the built-
in BOP
5
Commissioning via the
SINAMICS V20 Smart
Access
6
Communicating with the PLC
7
Parameter list
8
Faults and alarms
9
Technical specifications
A
Options and spare parts
B
General license conditions
C

Siemens SINAMICS V20 Specifications

General

Power Range	0.12 kW to 30 kW
Overload Capacity	150% for 60 seconds
Protection Class	IP20
Storage Temperature Range	-40°C to +70°C
Altitude	Up to 1000 m without derating
Input Voltage	3AC 380 V to 480 V
Output Voltage	0 V to Input Voltage
Control Modes	V/f control
Ambient Temperature Range	-10°C to +60°C
Relative Humidity	5% to 95%, non-condensing
Communication Interfaces	Modbus RTU
Braking Resistor	Optional external
