Parameter list
8
8.1 Introduction to parameters
Parameter number
Numbers prefixed with an "r" indicate that the parameter is a "read-only" parameter.
Numbers prefixed with a "P" indicate that the parameter is a "writable" parameter.
[index] indicates that the parameter is an indexed parameter and specifies the range of
indices available. If the index is [0...2] and the meaning is not listed, then see "Data set".
.0...15 indicates that the parameter has several bits, which can be evaluated or connected
individually.
Data set
Note
The
"Index" chapter at the end of this manual provides complete lists of CDS/DDS
parameters.
In the converter, the parameters which are used to define the sources for commands and
setpoints are combined in the
Command Data Set (CDS), while the parameters for the open
and closed-loop control of the motor are combined in the
Drive Data Set (DDS).
The converter can be operated from different signal sources by switching over the command
data sets. When switching over the drive data sets, it is possible to switch between different
converter configurations (control type, motor).
Three independent settings are possible for each data set. These settings can be made
using the index [0...2] of the particular parameter.
Index
CDS
DDS
[0]
Command data set 0
Drive data set 0
[1]
Command data set 1
Drive data set 1
[2]
Command data set 2
Drive data set 2
SINAMICS V20 has an integrated copy function which is used to transfer data sets. This can
be used to copy CDS/DDS parameters corresponding to the particular application.
Copy CDS
Copy DDS
Remarks
P0809[0]
P0819[0]
The data set which is to be copied (source)
P0809[1]
P0819[1]
The data set into which data is to be copied (target)
P0809[2] P0819[2]
= 1: Start copying
= 0: Copying completed
