Siemens SINAMICS V20 User Manual

SINAMICS V20 Converter
Operating Instructions, 10/2019, A5E34559884-012
3
Preface
Purpose of this manual
This manual provides you with information about the proper installation, commissioning,
operation, and maintenance of SINAMICS V20 converters.
SINAMICS V20 user documentation components
Document
Content
Available languages
Operating Instructions (this manual) English
Chinese (Simplified)
French
German
Italian
Korean
Portuguese
Spanish
Compact Operating Instructions Describes how you install, operate, and per-
form basic commissioning of the SINAMICS
V20 converter
English
Chinese (Simplified)
Bulgarian
Product Information Describes how you install and operate the
following options or spare parts:
• Parameter Loaders
• Dynamic Braking Modules
• External Basic Operator Panels (BOPs)
• BOP Interface Modules
• Migration mounting kit
• Shield Connection Kits
• I/O Extension Module
• Replacement Fans
English
Chinese (Simplified)
Describes how you install and operate the
following option:
• SINAMICS V20 Smart Access
English
Chinese (Simplified)
Chinese (Traditional)
Turkish
Spanish
Ukrainian
Serbian
Russian
Korean

Siemens SINAMICS V20 Specifications

General

Power Range	0.12 kW to 30 kW
Overload Capacity	150% for 60 seconds
Protection Class	IP20
Storage Temperature Range	-40°C to +70°C
Altitude	Up to 1000 m without derating
Input Voltage	3AC 380 V to 480 V
Output Voltage	0 V to Input Voltage
Control Modes	V/f control
Ambient Temperature Range	-10°C to +60°C
Relative Humidity	5% to 95%, non-condensing
Communication Interfaces	Modbus RTU
Braking Resistor	Optional external
