Table A-19 Invalid read request
Read request Inverter response
Invalid register address Exception code 02 (invalid data address)
Read a write-only register Telegram in which all values are set to 0.
Read a reserved register
Controller addresses more than 125 registers Exception code 03 (invalid data value)
The start address and the number of registers of an
address are located outside of a defined register block
Exception code 02 (invalid data address)
Structure of a write request via Modbus function code 06 (FC 06)
Start address is the holding register address.
Via FC 06, with one request, only precisely one register can be addressed. The value, which
is written to the addressed register, is contained in bytes 10 and 11 of the write request.
Table A-20 Structure of a write request for device number 17, example
Value Byte Description
MBAP header
06 h
00 h
63 h
55 h
66 h
7
8
9
10
11
Function code
Register start address "High" (write register 40100)
Register start address "Low"
Register data "High"
Register data "Low"
The response returns register address (bytes 8 and 9) and the value (bytes 10 and 11), which
the higher-level control had written to the register.
Table A-21 Device response to the write request, example
Value Byte Description
MBAP header
06 h
00 h
63 h
55 h
66 h
7
8
9
10
11
Function code
Register start address "High"
Register start address "Low"
Register data "High"
Register data "Low"
Table A-22 Invalid write request
Write request Inverter response
Incorrect address (a holding register address does not exist) Exception Code 02 - invalid data ad‐
dress
Write to a "read-only" register Exception Code 04 - device failure
Write to a reserved register
For Exception Code 4, via the holding register 40499, you can read out the internal drive error
code, which has occurred for the last parameter access via the holding register.
Communication
A.1 Communication
Industrial Security
Configuration Manual, 08/2017, A5E36912609A 183
