Siemens Drive Object, Instance Number: 32C hex
Supported services
Class ● Get Attribute single Instance ● Get Attribute single
● Set Attribute single
Table A-39 Class Attribute
No. Service Type Name
1 get UINT16 Revision
2 get UINT16 Max Instance
3 get UINT16 Num of Instances
Table A-40 Instance Attribute
No. Service Name Value/explanation
2 get, set Commisioning state p0010 Commissioning, parameter filter
3 … 18 get STW1 STW1 bit-by-bit access:
Attr.3 = STW1.0
Attr.18 = STW1.15
19 get Main setpoint Main setpoint
20 … 35 get ZSW1 ZSW1 bit-by-bit access:
Attr.20 = ZSW1.0
Attr.35 = ZSW1.15
36 get Actual Frequency Main actual value (actual frequency)
37 get, set Ramp Up Time p1120[0] ramp-function generator
ramp-up time
38 get, set Ramp Down Time p1121[0] ramp-function generator
ramp-down time
39 get, set Current Limit p0640[0] current limit
40 get, set Frequency MAX Limit p1082[0] maximum speed
41 get, set Frequency MIN Limit p1080[0] minimum speed
42 get, set OFF3 Ramp Down Time p1135[0] OFF3 ramp-down time
43 get, set PID Enable p2200[0] technology controller enable
44 get, set PID Filter Time Con‐
stant
p2265 Technology controller actual val‐
ue filter time constant
45 get, set PID D Gain p2274 technology controller differen‐
tiation time constant
46 get, set PID P Gain p2280 Technology controller propor‐
tional gain
47 get, set PID I Gain P2285 Technology controller integral
action time
48 get, set PID Up Limit p2291 technology controller maximum
limiting
49 get, set PID Down Limit p2292 technology controller minimum
limiting
