Siemens SINAUT ST7 - Page 27

Mounting and Installation
6NH7811-0AA22 © Siemens AG 2002 All Rights Reserved
2-8 MD2 Modem (07/2002)
Table 2-8 Configuration of Standard Cable 6NH1701-7AN
DTE/TIM11
(RS232)
Pin no. Connection Pin no. MD3 Modem
(RS232)
11
32
23
18 4
75
66
47
88
22 9
Table 2-9 Configuration of Standard Cable 6NH1701-7BK
DTE/TIM011B
(RS232)
Pin no. Connection Pin no. MD3 Modem
(RS232)
11
32
23
20 4
75
66
47
58
22 9
Sub-D socket
9-pin
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI / T
54321
9876
113
14 25
Sub-D Plug
25-pin
Sub-D socket
9-pin
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI / T
54321
9876
113
14 25
Sub-D Plug
25-pin
