Siemens SINUMERIK 802C User Manual

Technical Appendix
6.2 PLC user interface signals
6-111
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Status signals: Axes in WCS
3300 Signals from NCK channel [r]
Data block
Interface NCK –––––> PLC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Axis 1 in WCS
33001000 Traversing command Handwheel active
plus minus 2 1
Axis 1 in WCS
33001001 Machine function
continu-
ous
1000 INC 100 INC 10 INC 1 INC
33001002
33001003
Axis 2 in WCS
33001004 Traversing command Handwheel active
plus minus 2 1
Axis 2 in WCS
33001005 Active machine function
continu-
ous
1000 INC 100 INC 10 INC 1 INC
33001006
33001007
Axis 3 in WCS
33001008 Traversing command Handwheel active
plus minus 2 1
Axis 3 in WCS
33001009 Active machine function
continu-
ous
1000 INC 100 INC 10 INC 1 INC
33001010
33001011
