Technical Appendix
6.2 PLC user interface signals
6-112
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Transfer of auxiliary functions from the NC channel
2500 Auxiliary functions from NCK chan-
nel [r]
Data block
Interface PLC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Modify de-
25000000
coded
M func-
M func-
tions 0–99
25000001 Modify
T funct. 1
25000002
25000003
Decoded M signals (M0 – M99)
2500 M functions from NCK channel [r]
Data block
Interface NCK
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Dynamic M functions
25001000
M7 M6 M5 M4 M3 M2 M1 M0
Dynamic M functions
25001001
M15 M14 M13 M12 M11 M10 M9 M8
Dynamic M functions
25001002
M23 M22 M21 M20 M19 M18 M17 M16
...
...
...
Dynamic M functions
25001012
M99 M98 M97 M96
25001013
