Siemens SINUMERIK 802C User Manual

Start-Up
4.7 Commissioning
4-76
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Number
Default Va-
lue
Explanation
31060 Numerator load gearbox (control parameter set no.): 0...5 1
31070 Denominator resolver gearbox (encoder no.) 1
31080 Numerator resolver gearbox (encoder no.) 1
32100 Traversing direction (not control direction) 1
32110 Sign actual value (control direction) (encoder no.) 1
32200 Servo gain factor (control parameter set no.): 0...5 1
32250 Rated output voltage 80
32260 Rated motor speed (setpoint branch): 0 3000
32700 Interpolatory compensation (encoder no.): 0,1 0
33050
Traversing distance for lubrication from PLC 100 000
000
35010 Gear change possible. Spindle has several gear steps 0
35040 Own spindle reset 0
35100 Maximum spindle speed 10000
35110 Maximum speed for gear change (gear stage no.): 0..5 500,...
35120 Minimum speed for gear change (gear stage no.): 0..5 50,...
35130 Maximum speed of gear stage (gear stage no.): 0...5 500,...
35140 Minimum speed of gearsetp (gear stage no.): 0...5 5,...
35150 Spindle speed tolerance 0.1
35160 Spindle speed limitation from PLC 1000
35220 Speed for reduced acceleration 1.0
35230 Reduced acceleration 0.0
35300 Position control switch-on speed 500
35350 Direction of rotation when positioning 3
35400 Reciprocation speed 500
35410 Acceleration during reciprocating 16
35430 Starting direction during reciprocation 0
35440 Reciprocation time for M3 direction 1
35450 Reciprocation time for M4 direction 0,5
35510 Feedrate enable for spindle stopped 0
36000
(only
SPOS)
Exact positioning coarse
0.04
36010
(only
SPOS)
Exact positioning fine
0.01
36020
(only
SPOS)
Delay exact positioning fine
1
