Siemens SINUMERIK 802C User Manual

Start-Up
4.7 Commissioning
4-78
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Example 1 for encoder matching:
Axis with rotary encoder (500 pulses) mounted directly on the motor. The internal multiplica-
tion factor is 4. The internal computational resolution amounts to 1,000 increments per de-
gree.
MD
310
20 @
4
360 degrees
Inter-
nal
reso-
lution
=
M
D
3
1
0
7
0
MD31080
@@
1
0
0
0
5
0
0
@
4
@
1
360 @ 1 @ 1000
Inter-
nal
reso-
lution
=
=
1
8
0
One encoder increment corresponds to 180 internal increments. One encoder increment cor-
responds to 0.18 degrees (minimum positioning step).
Example 2 for encoder matching:
Spindle with rotary encoder on motor (2,048 pulses), internal multiplication = 4, 2 speed sta-
ges exist:
Gear stage 1: Motor/spindle = 2.5/1
Gear stage 2: Motor/spindle = 1/1
