Commissioning the system
1.5 BIOS settings for PCU 50.5
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
39
BIOS setup: Default settings
The following system parameters are saved on delivery:
Menu: Main
System parameters
Default settings
Own entries
System Time
hh:mm:ss
System Date
MM/TT/JJJJ
Menu: Advanced
Peripheral Configuration
Default settings
Own entries
Internal COM 1
Enabled
Onboard Ethernet 1
Enabled
Onboard Ethernet 2
Enabled
PCI - MPI / DP
1)
Enabled
1)
only for CPB (-C)
SATA Configuration
Default settings
Own entries
SATA Controller
Enabled
SATA Controller mode
AHCI
Video Configuration
Default settings
Own entries
Primary video device
PEG
USB Configuration
Default settings
Own entries
USB Port0
Enabled
USB Port1
Enabled
USB Port2
Enabled
USB Port3
Enabled
USB Port4 Enabled
USB Port5
Enabled
USB Port6
Enabled
USB Port7
Enabled
USB Port8
Enabled
USB Port9
Enabled
USB Port10
Enabled
