Configuring the system

2.3 Customized settings during boot up

PCU-Basesoftware (IM8)

Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0

SeqAct=262143

# Filtering Concurrent Keys

# =========================

# Definition and selection of function keys (buttons) which shall not be

# pushed in parallel or at the same time (function keys F1-F12 and

# additional hardkeys).

# If more of these buttons are pushed at the same time, the system removes the

# code of these buttons except the code of the button which was pushed first.

# This function of the keyboard-driver is activated by ConcurrentKeyEnable.

# ConcurrentKeyMask holds a BIT-Pattern for a max of 17 function keys, which

# must not be pushed simultaneously (concurrently). If bit-n is set in

# ConcurrentKeyMask, the corresponding button is supervised.

# The following 17 function keys are implemented:

# F1

# F2

# F3

# F4

# F5

# F6

# F7

# F8

# F9

# F10

# F11

# F12

# PAGE-UP (NUMLOCK) Alarm Hardkey on Operator Panel

# PAGE-DOWN (NUMLOCK) Tool Management Hardkey on Operator Panel

# HOME (NUMLOCK) Program Manager Hardkey on Operator Panel

# END (NUMLOCK) Program Hardkey on Operator Panel

# CURSOR-DOWN (NUMLOCK) Alarm Hardkey on Operator Panel

Note

Scope of the keys

Only keys, which have already been defined in the system.in

i file, can be enabled.

No additional keys can be defined for filtering.
