Siemens SINUMERIK 804D sl Commissioning Manual

Backing up and restoring data
4.6 Restore a disk image of the SSD
PCU-Basesoftware (IM8)
96 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
3. Make the required settings here:
Section
Settings
Purpose
Base
parameters
Source file Select the disk image from which the SSD is to be restored.
You can use local disk images or disk images stored in the
network.
Destination disk
Select the SSD to be restored from the disk image.
Base
parameters >
Destination
disk
Connect share Open the "Connect a Share" dialog box (Page 102).
You can manage a shared resource (e.g. a directory in the
network), to use a disk image stored on the network to restore
the SSD.
Select source Open the "Select Source File" dialog box.
You can navigate through a local directory on the PCU 50.5
and select a disk image for restoration.
Optional
parameters
Adjust
partitions
Select partition scheme to be used on restoration of the data
medium image:
• If the PCU base software Windows 7 is on the disk image,
choose "PCU Base Windows 7 partition scheme".
• If the PCU base software Windows XP is on the disk
image, choose "PCU Base Windows XP partition scheme".
It is not possible to use a different operating system on a PCU
50.x than the preinstalled system (e.g. Windows XP on a
PCU 50.5 Windows 7).
4. To start the restore process and entirely replace the existing data on the SSD with the
disk image, confirm the settings with "Restore".
Result
The restore process is started.
Note
Troubleshooting if reading in of the disk image fails
If data transf
er is interrupted during the restore process, the PCU will have no executable
system.
In this case, use a bootable USB flash drive with Service Center to read the disk image in
again.
