Entries Meaning
Icon9 - for milling technology Icon representing the tool type.
The icons are displayed in the following windows:
● "Tool List" in the "Type" column
● "New Tool - Favorites" in the "Tool position" column
● "New Tool - Milling Cutter 100 - 199" in the "Tool position" column
● "New Tool - Drill 200 - 299" in the "Tool position" column
● "New Tool - Special Tool 700 - 900 in the "Tool position" column.
The icons are in ".png" format. They are stored according to image res‐
olution in the following directories:
/oem/sinumerik/hmi/ico/ico640, oder ico800, or ico1024
/user/sinumerik/hmi/ico/ico640, oder ico800, or ico1024
IconX - for the turning and
grinding technologies
Icon representing the tool type (see Icon9 - for milling technology)
Special feature - tool positions are supported in the turning and grinding
technologies.
X is for the tool position represented by the icon. Position 9 is an unde‐
fined position represented by a cross.
Icon9_2 Icon representing the tool type in cutting edge position 9. It is used when
cutting edge position 9 is to be treated as a valid cutting edge position.
(see <SETTINGS> - CreateNewToolWithCuttPos9Enabled, Chapter
"General settings (Page 172)")
Iconorder Order in which the tool positions, represented by icons, are switched.
DisableInNewToolDialog With this entry, the tool type in question is not offered when new tools
are created. If the tool list finds a tool of this type that already exists, it is
correspondingly displayed.
DELETE_TOOLTYPE All predefined tool types that are not to be supported in the tool lists.
GrindingTooltypes All tool types that are to be used as grinding tool types.
Example 1
<TOOLTYPECONFIGURATION>
<TOOLTYPE_120>
<Tooltype value="120" type="uint" />
<Name value="TM_PAR_SHANK_END_CUTTER" type="QString" />
<Shortname value="TM_PPTT_SHANK_END_CUTTER" type="QString" />
<Tooltip value="TM_TTTT_SHANK_END_CUTTER" type="QString" />
<Icon9 value="to_poly_shank_end_cutter_down.png" type="QString" />
</TOOLTYPE_120>
</TOOLTYPECONFIGURATION>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
198 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
