[1] Stop dimensions
[2] Jaw dimensions
MD53241 $MAS_SPINDLE_CHUCK_TYPE[ ] Spindle jaw type
= 0 Clamping, outer
= 1 Clamping, inner
Additional settings
The M code, e.g. M34 or M1 = 34 for the spindle chuck is defined in the following machine
data. The manufacturer cycle CUST_TECHCYC.SPF also takes the M functions from the
following machine data:
MD52250 $MCS_M_CODE_CHUCK_OPEN[ ] M code for open chuck with station‐
ary spindle
[0] Main spindle
[1] Counterspindle
MD52251 $MCS_M_CODE_CHUCK_CLOSE_OPEN_ROT[ ] M code for open chuck with spindle
rotating
[0] Main spindle
[1] Counterspindle
MD52252 $MCS_M_CODE_CHUCK_CLOSE[ ] M code for close chuck
[0] Main spindle
[1] Counterspindle
MD52253 $MCS_M_CODE_TAILSTOCK_FORWARD[ ] M code for quill forward
[0] Quill opposite the main spindle
[1]
MD52254 $MCS_M_TAILSTOCK_BACKWARD[ ] M code for quill back
[0] Quill opposite the main spindle
[1] Quill opposite the main spindle
Contour turning (CYCLE952)
SD55212 $SCS_FUNCTION_MASK_TECH_SET General function screen for all technologies
= 6
Bit 3 Delete programs generated by contour cycles (CYCLE63, CYCLE64, CYCLE952)
= 0 Generated programs are not deleted (compatibility as before)
= 1 Generated programs are deleted as soon as they have been executed by the calling cycle.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
532 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
