Tag identifier Meaning
OPEN_FORM The tag opens the dialog form given under the name.
Attribute:
● name
Name of the dialog form
Syntax:
<OPEN_FORM name = "<form name>" />
Example:
<menu name = "main">
<open_form name = "main_form" />
<softkey POSITION="1">
<caption>main form</caption>
<navigation>main</navigation>
</softkey>
</menu>
<form name="main_form">
<init>
</init>
<paint>
</paint>
</form>
Generating user dialogs
1.7 XML identifier
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 69
