Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
2-228 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Area Address Message number
Axis/spindle 11 DBX164.0 - DBX165.7 601.100 - 601.115
Axis/spindle 12 DBX166.0 - DBX167.7 601.200 - 601.215
Axis/spindle 13 DBX168.0 - DBX169.7 601.300 - 601.315
Axis/spindle 14 DBX170.0 - DBX171.7 601.400 - 601.415
Axis/spindle 15 DBX172.0 - DBX173.7 601.500 - 601.515
Axis/spindle 16 DBX174.0-DBX175.7 601.600 - 601.615
Axis/spindle 17 DBX176.0 - DBX177.7 601.700 - 601.715
Axis/spindle 18 DBX178.0 - DBX179.7 601.800 - 601.815
Axes 19 to 31 are not currently
implemented
User areas in DB 2
Area Address Message number
User area 0 DBX180.0 - DBX187.7 700.000 - 700.063
User area 1 DBX188.0 - DBX195.7 700.100 - 700.163
User area 2 DBX196.0 - DBX203.7 700.200 - 700.263
User area 3 DBX204.0 - DBX211.7 700.300 - 700.363
User area 4 DBX212.0 - DBX219.7 700.400 - 700.463
User area 5 DBX220.0 - DBX227.7 700.500 - 700.563
User area 6 DBX228.0 - DBX235.7 700.600 - 700.663
User area 7 DBX236.0 - DBX243.7 700.700 - 700.763
User area 8 DBX244.0 - DBX251.7 700.800 - 700.863
User area 9 DBX252.0 - DBX259.7 700.900 - 700.963
User area 10 DBX260.0 - DBX267.7 710.000 - 701.063
User area 11 DBX268.0 - DBX275.7 710.100 - 701.163
User area 12 DBX276.0 - DBX283.7 710.200 - 701.263
User area 13 DBX284.0 - DBX291.7 710.300 - 701.363
User area 14 DBX292.0 - DBX299.7 710.400 - 701.463
User area 15 DBX300.0 - DBX307.7 710.500 - 701.563
User area 16 DBX308.0 - DBX315.7 710.600 - 701.663
User area 17 DBX316.0 - DBX323.7 710.700 - 701.763
User area 18 DBX324.0 - DBX331.7 710.800 - 701.863
User area 19 DBX332.0 - DBX339.7 710.900 - 701.963
User area 20 DBX340.0 - DBX347.7 702.000 - 702.063
User area 21 DBX348.0 - DBX355.7 702.100 - 702.163
User area 22 DBX356.0 - DBX363.7 702.200 - 702.263
User area 23 DBX364.0 - DBX371.7 702.300 - 702.363
User area 24 DBX372.0 - DBX379.7 702.400 - 702.463
