Detailed Description
2.3 Continuous-path mode
Continuous-Path Mode, Exact Stop, LookAhead (B1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-35
Value frange for index n = 0 to 4
Example of programming with index:
MD32300: MAX_AX_ACCEL[3, AX1]=1
R1=MD20602: CURV_EFECT_ON_PATH_ACCEL[4]
Notice
Writing the machine data without an index places the same value in all field elements of the
machine data in question.
Reading the machine data without an index always supplies the value of the field with
index 0.
These constellations can occur:
1. Write from part program MD32300: MAX_AX_ACCEL[AX1]=1 sets all five field elements to
value 1 (unit of measurement metric or inch depending on axis type and reference system).
2. Read in archive files from software versions earlier than SW 7.2.
Activate parameter sets for dynamic response
By programming G codes, the machine data affecting dynamics are activated and assigned
as follows:
Active parameter set G CODE of group 59 technology:
Index 0: Value for: DYNNORM
Index 1: Value for: DYNPOS
Index 2: Value for: DYNROUGH
Index 3: Value for: DYNSEMIFIN
Index 4: Value for: DYNFINISH
Note
We recommend suppressing G codes that are not used
with MD10712: NC_USER_CODE_CONF_NAME_TAB[n]. This will prevent these G codes
from being programmed accidentally and activating unconfigured machine data.
