Tables
15.1 List of statements
Job planning
Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
15-9
CTABTSV Returns the value of the following axis at curve
table start
Following value
at start of curve
table
R10 = CTABTSV(n,
degree, Faxis)
CTABUNLOCK Cancel locking against deletion and
overwriting
Parameters n,
m, and
memType
CTRANS Zero offset for multiple axes FRAME Max. of 8 axes
CUT2D
1
2½D cutter compensation (cutter
compensation type 2 dimensional)
m 22
CUT2DF 2½D tool offset (cutter compensation type 2
dimensional frame); The tool offset acts in
relation to the current frame (inclined plane)
m 22
CUT3DC
5
3D cutter compensation type 3-dimensional
circumference milling
m 22
CUT3DCC
5
Cutter compensation type 3-dimensional
circumference milling with limit surfaces
m 22
CUT3DCCD
5
Cutter compensation type 3-dimensional
circumference milling with limit surfaces with
differential tool
m 22
CUT3DF
5
3D cutter compensation type 3-dimensional
face milling
m 22
CUT3DFF
5
3D cutter compensation type 3-dimensional
face milling with constant tool orientation
dependent on the current frame
m 22
CUT3DFS
5
3D cutter compensation type 3-dimensional
face milling with constant tool orientation
independent of the current frame
m 22
CUTCONO
1
Constant radius compensation OFF m 40
CUTCONON Constant radius compensation ON m 40
D Tool offset number 1, ... 32 000 Contains the
correction data
for a specific
tool T... ; D0 →
correction
values for a
tool
D...
DC Absolute dimensions for rotary
axes, approach position directly
A=DC(...) B=DC(...)
C=DC(...)
SPOS=DC(...)
s
DEF Variable definition Integer, w/o
signs
