Tables
15.1 List of statements
Job planning
15-12 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
ENDPROC
End line of program with start line PROC
ENDWHILE End line of WHILE loop
ETAN Tangential transition to next traversing block at
spline end (end tangential)
m 20
EVERY Execute synchronized action if condition
changes from FALSE to TRUE
EXECSTRING Transfer of a string variable with the parts
program line to run
Indirect parts
program line
EXECSTRING(MFC
T1 << M4711)
EXECTAB Execute an element from a motion table
(execute table)
EXECUTE Program execution ON Return from
the reference
point edit mode
or after building
a protection
area to the
normal
program
processing
EXP Exponential function (e
x
) Real
EXTCALL Execute external subroutine Reload
program from
HMI in
"Processing
from external
source" mode
EXTERN Broadcast a subroutine with parameter
passing
F Feed value
(in conjunction with G4 the dwell
time is also programmed in F)
0.001, ...,
99 999. 999
Tool/workpiece
path feedrate;
unit of
measurement
in mm/min or
mm/rev
dependent on
G94 or G95
F=100 G1 ...
FA Axial feed (feed axial) 0.001, ...,
999999.999
mm/min,
degrees/mi
n, 0.001, ...,
39999.9999
inch/min
FA[X]=100 m
FAD Infeed feedrate for smooth
approach and retraction
(Feed approach / depart)
Real, w/o
signs
