Tables
15.1 List of statements
Job planning
15-16 Programming Manual, 03/2006 Edition, 6FC5398-2BP10-1BA0
G33
Thread interpolation with
constant pitch
0.001, ...,
2000.00
mm/rev
Motion command G33 Z... K... SF=...
;cylindrical thread
G33 X... I... SF=...
;face thread
G33 Z... X... K... SF=...
;taper thread (in Z
axis;path larger than in
the X axis)
G33 Z... X... I... SF=...
;taper thread (in X
axis;path larger than in
the Z axis)
m 1
G34 Increase in thread pitch
(progressive change)
Motion command G34 Z... K... F
UP
=... m 1
G35 Decrease in thread pitch
(degressive change)
Motion command G35 Z... K... F
DOWN
=... m 1
G40
1
Tool radius compensation OFF m 7
G41 Tool radius compensation left of contour m 7
G42 Tool radius compensation right of contour m 7
G53 Suppression of current zero offset (non-
modal)
incl.
programmed
offsets
s 9
G54 1. Settable zero offset m 8
G55 2. Settable zero offset m 8
G56 3. Settable zero offset m 8
G57 4. Settable zero offset m 8
G58 Programmable offset Replacing axially s 3
G59 Programmable offset Replacing
additively axially
s 3
G60
1
Exact stop - deceleration m 10
G62 Corner deceleration at inside corners
when tool radius offset is active (G41, G42)
Together with
continuous-path
mode only
G62 Z... G1 m 57
G63 Tapping with compensating chuck G63 Z... G1 s 2
G64 Exact stop - continuous-path mode m 10
G70 Dimension in inches (lengths) m 13
G71
1
Metric dimension (lengths) m 13
G74 Reference point approach G74 X... Z...;separate
block
s 2
G75 Fixed point approach Machine axes G75 FP=.. X1=... Z1=...
;separate block
s 2
G90
1
Absolute dimensions G90 X... Y... Z...(...)
Y=AC(...) or
X=AC Z=AC(...)
m
n
14
G91 Incremental dimension input G91 X... Y... Z... or
X=IC(...) Y=IC(...)
Z=IC(...)
m
n
14
