4.8 CCU1: 6th axis (SW 3.2 and higher)
4-82
E Siemens AG, 2002. All rights reserved
SINUMERIK 810D Manual Hardware Configuration (PHC) -- 11.02 Edition
Table 4-19 Recommended choice of lengths for drive bus cables
Order no.
Module width to be
bridged in mm
Comments
6SN1 161-1CA00-0BA1
50 Drive bus cable, round
cable, shielded
6FC5247-0AA28-0AA0
50 Device bus cable
6
F
C
5
2
4
7
0
A
A
2
8
0
A
A
0
GWE: 462008006403
50 Device bus cable
6SN1 161-1AA00-0BA0
<50 Device bus cable 400mm
NC60 Catalog: choose
length + 50mm
<50 Drive bus cable, round
cable, shielded
