6.1 Single I/O module
6-94
E Siemens AG, 2002. All rights reserved
SINUMERIK 810D Manual Hardware Configuration (PHC) -- 11.02 Edition
Connection of inputs 0--31
Connector designation: X404 INPUT 0--31
Connector type: 34--way DIN ribbon cable connection
Length of ribbon cable: Max. of 3m to terminal block
1 Unassigned 2 Unassigned
3
INP00
I 4
INP01
I
5
INP02
I 6
INP03
I
7
INP04
I 8
INP05
I
9
INP06
I 10
INP07
I
11
INP10
I 12
INP11
I
13
INP12
I 14
INP13
I
15
INP14
I 16
INP15
I
17
INP16
I 18
INP17
I
19
INP20
I 20
INP21
I
21
INP22
I 22
INP23
I
23
INP24
I 24
INP25
I
25
INP26
I 26
INP27
I
27
INP30
I 28
INP31
I
29
INP32
I 30
INP33
I
31
INP34
I 32
INP35
I
33
INP36
I 34
INP37
I
Signal names
INPiξjζ Input j of input byte i
Signal type
I Input
Connection of inputs 32--63
Connector designation: X405 INPUT 32--6 3
Connector type: 34-way DIN ribbon cable connection
Length of ribbon cable: Max. of 3m to terminal block
1 Unassigned 2 Unassigned
3
INP40
I 4
INP41
I
5
INP42
I 6
INP43
I
7
INP44
I 8
INP45
I
9
INP46
I 10
INP47
I
11
INP50
I 12
INP51
I
13
INP52
I 14
INP53
I
15
INP54
I 16
INP55
I
17
INP56
I 18
INP57
I
19
INP60
I 20
INP61
I
21
INP62
I 22
INP63
I
23
INP64
I 24
INP65
I
25
INP66
I 26
INP67
I
X404
Inputs 0 --31
X405
Inputs 32--63
